| | | MIN | MAX | UNIT |
| Vcc | 5-V bus supply voltage range | -0.3 | 7 | V |
| Mio | VO Level Shifting Voltage Range | Devices with the "V"suffix | -0.3 | 7 | V |
| Vpus | CAN Bus I/O voltage range
(CANH,CANL) | Devices without the "H"suffix | -58 | 58 | V |
| V(oim | Max differential voltage between
CANH and CANL | Devices without the“H”suffix | -58 | 58 | V |
| VBUS | CAN Bus I/O voltage rang
(CANH,CANL) | Devices with the "H"suffix | -70 | 70 | V |
| Vpit | Max differential voltage between
CANH and CANL | Devices with the"H"suffix | -70 | 70 | V |
| Vilogic Imput | Logic input teminal voltage range (TXD,STB) | -0.3 | 7 and V₁≤Vio+0.3 | V |
| Vilosic Ouput | Logic output terminal voltage range (RXD) | -0.3 | 7 and V≤Vio+0.3 | V |
| lo(RxD | RXD(Receiver)output current | -8 | 8 | mA |
| TJ | Virtual junction temperature range(see Thermal Information | -55 | 150 | ℃ |
| Tsrg | Storage temperature range (see Themal Information) | -65 | 150 | ℃ |
